System
Highlights |
 |
 |
Unrivaled base-to-base capability, seamlessly integrating with virtually any power base in the industry |
 |
Our most modular system, featuring up to 50° of CG Tilt, 170° of Recline and up to 12" of nearly
silent Power Seat Elevation |
 |
Available with the full range of Motion Concepts’ accessories and Invacare® Matrx® Seating products, mounted via our all new Ultra Rail and Ultra Track slotted interfaces |
 |
300 lb. weight capacity |
 |
Seat-to-Floor Heights as low as 16¾" depending on power base |
 |
Telescoping
legrest receivers adjust independently of system |
 |
14" - 22" of seat width and 14" - 23" seat depth adjustment |
 |
This
entire system can be moved from one power base to another
with a simple interface change |
 |
Ideal
for today's smaller power bases |
 |
Compatible
with virtually every major power base |
 |
Most
modular system in the industry |
|
Standard
Features |
 |
300
lbs Standard Weight Capacity |
 |
All
Systems come with the seat pan, standard back pan, armrests,
armpads and fixed center mount front rigging |
 |
Standard
Seat Widths: 16" - 22" |
 |
Standard
Seat Depths (Slotted adjustment in 3" ranges):16" - 23" |
 |
Lifetime
Structural Warranty |
|
Positioning
Options |
 |
Tilt
Only: 50° CG Tilt |
 |
50° CG Tilt
and Recline System: 170° Recline with Extended Shear Reduction (ESR) |
 |
50° CG Tilt
and Recline System: 170° Recline with Power Sliding Back (PSB)) |
 |
Recline System with with Extended Shear Reduction (ESR) |
 |
Recline System with with with Power Sliding Back (PSB)) |
 |
12" Elevate Lift Seat |
|
Modules |
 |
Anterior
Tilt: up to 45° |
 |
Fixed Anterior
Assist: 5°, 10° |
 |
Pre-tilt: 5° |
 |
Power Lateral Tilt: up to 15° (Left and Right) |
 |
Precline Module: 8° |
 |
Precline Module: 30° |
 |
Single Post Angle Adjustable Fold Down Back (Matrx or Contour Back) |
 |
12" Elevate Lift Seat |
|
Matrx
Seating Option |
 |
Matrx PS, PSP, Vi, and Libra Cushions |
 |
Matrx Elite, Elite HD, Elite TR, Elite Deep, lite PB, PB Deep, PB HD, PB HD Deep Backs |
 |
Matrx Elan Headrest |
|
Front
Rigging Option |
 |
Invacre 70° Swing-away Footrests
|
 |
LNX Power Center Mount Foot Platform |
 |
Power Telescoping Foot Platform for LNX |
 |
Power Flip up foot platform for LNX |
 |
Vertical Lifting Platform |
 |
Power Telescoping Foot Platform Fixed Center Mount |
 |
Power Flip-up foot Platform for Power Telescoping Foot Platform Fixed Center Mount |
 |
Maxx Style Swing Away Power or Manual Elevating Pivot Legrests |
 |
Swing Away Power Elevating Pivot Plus Legrests |
 |
Pivot Plus Manual Elevating Legrests |
 |
Heavy Duty 70° Swing Away footrests |
 |
Maxx Style Fixed Center Mount Foot Platform70°-90° Fixed Center Mount Foot Platform |
 |
Invacare Split Foot Platform Interface Brackets70°-90° Fixed Center Mount Foot Platform |
|
Electronics |
 |
Standard
Electronics |
 |
Enhanced
Electronics |
 |
Electronics
Accessories |
|
Accessories
and Options |
 |
Motion
Concepts Headrests, Stealth Comfort Plus and Combination Headrest |
 |
Modular, Standard,
Waterfall, Flat Gel Arm Pads and Ergonomic Arm Troughs |
 |
Armrest
Storage Compartment and Arm Pad Storage/Cup Holder |
 |
Lateral
Trunk Supports and Hip Supports, removable or fixed |
 |
Transfer
Handles |
 |
Safety Lights |
 |
Single
and Double Backpacks |
 |
Endomorph
Back Canes |
|
Vent Trays and O2 Holders |
 |
Articulating,
Gimbal and Laptop Style Vents (on select systems sizes and
bases only) |
 |
Liquid
and Gas O2 Holders |
|
